ATTACHMENT

BACKHOES

Since they don’t require removal of the lower 3-point hitch arms, our sub-frame mounted, quick-attach backhoes are time-savers even before you start digging in.

BACKHOES

LB1104

  • Digging Depth (in): 79.3
  • Reach From centerline of swing Pivot (in): 113.3
  • Loading Height (in): 56.9
  • Swing Arc (deg.): 150
  • Transport Height (in): 75.2
  • Bucket Rotation (deg.): 163
  • Stabilizer Spread (Down Position) (in): 87.7
  • Stabilizer Spread (Up Position) (in): 55.7
  • Bucket Digging force (lbs): 2,096

COMPATIBLE WITH

XJ2025

Backhoe Lifestyle Image
*Exact model shown may vary
Backhoe Lifestyle 3
*Exact model shown may vary

BACKHOES

LB1105

  • Digging Depth (in): 76.3
  • Reach From centerline of swing Pivot (in): 113.1
  • Loading Height (in): 63.6
  • Swing Arc (deg.): 180
  • Transport Height (in): 77.2
  • Bucket Rotation (deg.) :180
  • Stabilizer Spread (Down Position) (in): 68.7
  • Stabilizer Spread (Up Position) (in): 46.4
  • Bucket Digging force (lbs.): 2,817

COMPATIBLE WITH

MT230E, MT235E, MT235HE, MT240E, MT240HE

BACKHOES

LB1106

  • Digging Depth (in): 76.3
  • Reach From centerline of swing Pivot (in): 113.1
  • Loading Height (in): 63.9
  • Swing Arc (deg.): 180
  • Transport Height (in): 77.2
  • Bucket Rotation (deg.): 180
  • Stabilizer Spread (Down Position) (in): 68.7
  • Stabilizer Spread (Up Position) (in): 46.4
  • Bucket Digging force (lbs): 2,817

COMPATIBLE WITH

MT225E

Backhoe Lifestyle 4
*Exact model shown may vary
Backhoe Lifestyle 2
*Exact model shown may vary

BACKHOES

LB1107

  • ​Digging Depth (in.): 75.1
  • Reach from Centerline of Swing Pivot (in.): 114.9
  • Loading Height (in.): 59.6
  • Swing Arc (deg.): 140
  • Transport Height (in.): 74.7
  • Bucket Rotating (deg.): 169.4
  • Stabilizer Spread (Down Position) (in.): 78.6
  • Stabilizer Spread (Up Position) (in.): 53.2
  • Bucket Digging Force (lbs.): 2,194
  • Shipping Weight (lbs.): 661

COMPATIBLE WITH

MT1 Series

BACKHOES

LB1300

  • Digging Depth (in): 84.9
  • Reach from centerline of swing Pivot (in): 113.7
  • Loading Height (in): 64.7
  • Swing Arc (deg.): 180
  • Transport Height (in): 73.4
  • Bucket Rotating (deg.): 177
  • Stabilizer Spread(Down position) (in): 82.2
  • Stabilizer Spread(Up position) (in): 65.4
  • Bucket Digging force (lbs.): 3,013

COMPATIBLE WITH

MT225S

LB1300 Backhoe
*Exact model shown may vary
LB3001

BACKHOES

LB3001

  • ​Digging Depth (in.): 97.2
  • Reach from Centerline of Swing Pivot (in.): 127.2
  • Loading Height (in.): 76.2
  • Swing Arc (deg.): 160
  • Transport Height (in.): 81.1
  • Bucket Rotating (deg.): 180
  • Stabilizer Spread (Down Position) (in.): 67.5
  • Stabilizer Spread (Up Position) (in.): 50
  • Bucket Digging Force (lbs.): 3,663

COMPATIBLE WITH

MT226E (ROPS)

BACKHOES

LB3002

  • Digging Depth (in): 97.2
  • Reach from centerline of swing Pivot (in): 127.2
  • Loading Height (in): 76.2
  • Swing Arc (deg.): 160
  • Transport Height (in): 81.8
  • Bucket Rotating (deg.): 180
  • Stabilizer Spread(Down position) (in): 67.5
  • Stabilizer Spread(Up position) (in): 50
  • Bucket Digging force (lbs.): 3,663

COMPATIBLE WITH

MT226E(CAB), MT232E, MT232HEC, MT232HC, MT232HE, MT232H, MT242HEC, MT242HE, MT242HC, MT242E, MT242H

LB3002

BACKHOES

LB2104

  • Digging Depth (in): 89.8
  • Reach from centerline of swing Pivot (in):125.2
  • Loading Height (in): 72.4
  • Swing Arc (deg.): 180
  • Transport Height (in): 83.5
  • Bucket Rotating (deg.): 180
  • Stabilizer Spread(Down position) (in): 68.7
  • Stabilizer Spread(Up position) (in): 46.5
  • Bucket Digging force (lbs): 2,673

COMPATIBLE WITH

XR3100 Series

BACKHOES

LB2105

  • Digging Depth (in): 89.8
  • Reach from centerline of swing Pivot (in): 125.2
  • Loading Height (in): 72.4
  • Swing Arc (deg.): 180
  • Transport Height (in): 83.5
  • Bucket Rotating (deg.): 180
  • Stabilizer Spread(Down position) (in): 68.7
  • Stabilizer Spread(Up position) (in): 46.5
  • Bucket Digging force (lbs): 2,673

COMPATIBLE WITH

MT3 Series

BACKHOES

LB2106

  • Digging Depth (in): 89.7
  • Reach from centerline of swing Pivot (in): 125.2
  • Loading Height (in): 72.4
  • Swing Arc (deg.): 180
  • Transport Height (in): 83.5
  • Bucket Rotating (deg.): 180
  • Stabilizer Spread(Down position) (in): 68.7
  • Stabilizer Spread(Up position) (in): 46.5
  • Bucket Digging force (lbs): 2,673

COMPATIBLE WITH

MT3E Series

BACKHOES

LB3101

  • Digging Depth (in): 94.4
  • Reach from centerline of swing Pivot (in):136.1
  • Loading Height (in): 80.3
  • Swing Arc (deg.): 180
  • Transport Height (in): 92.9
  • Bucket Rotating (deg.) 180
  • Stabilizer Spread(Down position), (in): 68.7
  • Stabilizer Spread(Up position) (in): 46.4
  • Bucket Digging force (lbs): 3,748

COMPATIBLE WITH

MT3 Series, XU Series

BACKHOES

LB3102

  • Digging Depth (in): 94.5
  • Reach from centerline of swing Pivot (in.): 136.2
  • Loading Height (in): 80.3
  • Swing Arc (deg.): 180
  • Transport Height (in): 92.9
  • Bucket Rotating (deg.): 180
  • Stabilizer Spread(Down position) (in): 68.7
  • Stabilizer Spread(Up position) (in): 46.5
  • Bucket Digging force (lbs): 3,740

COMPATIBLE WITH

XU Series

BACKHOES

LB3103

  • Digging Depth (in): 94.4
  • Reach from centerline of swing Pivot (in.): 136.1
  • Loading Height (in): 80.3
  • Swing Arc (deg.): 180
  • Transport Height (in): 92.9
  • Bucket Rotating (deg.): 180
  • Stabilizer Spread (Down position) (in): 68.7
  • Stabilizer Spread (Up position) (in): 46.4
  • Bucket Digging force (lbs): 3,748

BACKHOES

LB3104

  • Digging Depth (in): 94.4
  • Reach from centerline of swing Pivot (in.): 136.1
  • Loading Height (in): 80.3
  • Swing Arc (deg.): 180
  • Transport Height (in): 92.9
  • Bucket Rotating (deg.): 180
  • Stabilizer Spread(Down position) (in): 68.7
  • Stabilizer Spread(Up position) (in): 46.4
  • Bucket Digging force (lbs): 3,748

COMPATIBLE WITH

MT3 Series

BACKHOES

LB2103

  • Digging Depth (in): 89.7
  • Reach from centerline of swing Pivot (in): 125.1
  • Loading Height (in): 72.4
  • Swing Arc (deg.): 180
  • Transport Height (in): 83.5
  • Bucket Rotating (deg.): 180
  • Stabilizer Spread(Down position) (in):68.7
  • Stabilizer Spread(Up position) (in): 46.4
  • Bucket Digging force (lbs): 2,679
